2018 new auto 5kg to 50kg rice agro application packing machine
Detalles del producto
1, Product Name: 2018 new auto 5kg to 50kg rice agro application packing machine
2, Item: DCS-50L
Application Materials(products)
Gravity feeding type packing machine suit for pack small size granular or powder with good flow, such as plastic particles, feed, fertilizer( urea etc), grain, sugar, bean, rice etc.
Application Bags(open mouth bags)
This bagging machine is especially designed for pack materials(products) into open mouth bags, such as plastic woven bags, kraft bags,paper-plastic compound bags, sacks, barrel etc
Automatic filling - automatic weighing - manually bag placing - automatic bag clamped - materials automatic discharge - automatic bag loose - automatic conveying - automatic bag closed by sewing/heat sealing
Control Box
+Full touch screen panel
+PLC system
+Photoelectric sensor switch
+English/Chinese view
+Easy operation interface
+Proction data record & print
+Connect computer available
Three pieces of Load Cell
(weighing sensor)
+Famous brand load cell, more stable
+Installed 3pieces load cell, high weighing accuracy
Three-travelling Air Cylinder
+Control by the PLC system and three-travelling
air cylinder, feeding speed with fast-midium-slow
Automtic Bag Clamp/Loose Mechanism
+Photoelectric sensor switch
+Big force 2pcs air cylinder control
+Automatic bag clamp and loose
+Automatic materials dischage
+Suit for different bag size
Dust Air Outlet
+All of our packing machine will install air outlet
+Connect your dust removal device, making the
working environment more hygienic
+Add our pulse dust collector,
dust collection≥99.8%
Automatic Sewing Machine
+Automatic bag top folding device(opitional)
+Photoelectric sensor switch
+Automatic knife thread cut
+Single needle double thread chain
+Production data record & print
+Thread end length ajustable
+Bag sewing heigth adjustable
+With automatic bag conveyor
